Omada Pro 24-Port PoE+Gigabit L2+Manag



TP-Link
Not in stock
€ 1.289,60
€ 1.560,41 incl 21% VAT
What This Product Does

The S5500-24GP4F provides 24 Ethernet ports (10/100/1000 Mbps) compliant with 802.3at/af PoE. Users can supply up to 250 W total power to connected devices and flexibly deploy equipment such as wireless access points or IP cameras without worrying about power outlets. PoE support together with high-performance static routing, enterprise-level QoS, advanced security features and a selection of Layer 2 management options make S5500-24GP4F a great choice for small and medium-sized businesses.

Layer 2 and Layer 3 features include Proxy ARP, Static Routing, OAM, L2PT, and DLDP to meet the needs of ISP customers, while IP-MAC-Port Binding, VLAN Binding, and Access Control List (ACL) functions protect against broadcast storms, ARP attacks, Denial-of-Service (DoS) attacks, and other threats. Quality of Service (QoS) provides enhanced traffic management capabilities to ensure fast transfers for your important data, even when the network is busy. Integration into the Omada Pro system brings centralized cloud management and a series of management features such as Zero-Touch Provisioning (ZTP) and Intelligent Anomaly Detection. Moreover, easy-to-use web management interfaces, along with CLI, SNMP, RMON, and Dual Image mean faster setup and configuration with less downtime. This cloud-manageable access switch is ideal for enterprise branch offices and campus networks, as well as SMBs.

IEEE 802.3at/af-compliant Power over Ethernet

24× IEEE 802.3at/af-compliant PoE ports supply up to 250 W total power to 802.3at and 802.3af devices. * Set up wireless access points, surveillance cameras, IP phones, and other PoE devices quickly and easily, without the hassle and cost of installing power cabling.

Secure Networking

Security features include IP-MAC-Port Binding and VLAN Binding, Port Security, Storm Control, and DHCP Snooping to defend against a range of network threats. An integrated list of common DoS attacks is available, making it easier than ever to prevent them. In addition, the Access Control Lists (ACL, L2 to L4) feature restricts access to sensitive network resources by denying packets based on source and destination MAC address, IP address, TCP/UDP ports, or VLAN ID. Users’ network access can be controlled via 802.1X authentication, which works with a RADIUS/Tacacs+ server to grant access only when valid user credentials are provided.

Advanced QoS

Leveraging IP, MAC, TCP, and UDP identifiers, our QoS feature ensures seamless voice and video transmission—even when bandwidth is in short supply.

Abundant L2 and L3 features

S5500-24GP4F supports a complete lineup of L2 features, including Proxy ARP, Static Routing, OAM, 802.1Q VLAN, Port Mirroring, STP/RSTP/MSTP, Link Aggregation Control Protocol, and 802.3x Flow Control. Advanced IGMP Snooping ensures the switch intelligently forwards multicast streams to only the appropriate subscribers, cutting out unnecessary traffic, while IGMP throttling & filtering restrict each subscriber on a port level to prevent unauthorized multicast access. Static Routing, an L2+ feature, is a simple way of segmenting the network and internally routes traffic through the switch for improved efficiency. Ethernet Ring Protection Switching (ERPS) blocks traffic on a single ring link to prevent looping and effectively adds redundancy and up-time protection to any network.

ISP Features

ERPS, L2PT, QinQ, L2PT PPPoE ID Insertion, and IGMP authentication features are provided, developed with service providers in mind. 802.3ah OAM and Device Link Detection Protocol (DLDP) offer easy monitoring and troubleshooting of Ethernet links.

IPv6 Support

IPv6 functions such as Dual IPv4/IPv6 Stack, MLD Snooping, IPv6 ACL, DHCPv6 Snooping, IPv6 Interface, Path Maximum Transmission Unit (PMTU) Discovery, and IPv6 Neighbor Discovery guarantee your network is ready for the Next Generation Network (NGN) without upgrading your hardware.

Integrated into Omada Pro

Integration into the Omada Pro system brings centralized cloud management and a series of management features such as Zero-Touch Provisioning (ZTP) and Intelligent Anomaly Detection. Omada Pro’s Software Defined Networking (SDN) platform integrates network devices, including access points, switches, and routers, providing 100% centralized cloud management. Omada Pro creates a highly scalable network—all controlled from a single interface. Seamless wireless and wired connections are provided, ideal for use in hospitality, education, retail, offices, and more.

Apart from the ability to be centrally managed via Omada Pro controllers, S5500-24GP4F is also easy to manage via an intuitive web-based Graphical User Interface (GUI) or an industry-standard Command Line Interface (CLI). For both management methods, traffic is protected through SSL or SSH encryption. SNMP (v1/v2c/v3) and RMON support enable the switch to be polled for valuable status information and to send traps for abnormal events.

Specification

Product
Product id 907023
Brand TP-Link
Partnr S5500-24GP4F
EAN/UPC code 4895252505634
Warranty (months) 3 year limited warranty for normal product and 5 year warranty for managed switch
Data transmission
MAC address table 8000 entries
Switching capacity 56 Gbit/s
Forwarding rate 41.66 Mpps
Store-and-forward Y
Number of queues 8
Static route Y
Number of static routes 48
Number of IP interfaces 32
Jumbo frames support Y
Jumbo frames 9000
Packet buffer memory 4.1 MB
Network
Networking standards IEEE 802.1D, IEEE 802.1Q, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3az, IEEE 802.3i, IEEE 802.3u, IEEE 802.3x
10G support N
Port mirroring Y
Active link detection Y
Flow control support Y
Spanning tree protocol Y
Rate limiting Y
Broadcast storm control Y
Link aggregation Y
Virtual LAN features MAC address-based VLAN, Protocol-based VLAN, Voice VLAN
Number of VLANs 4000
Management features
Switch type Managed
Switch layer L2/L2+
Quality of Service (QoS) support Y
Web-based management Y
Configuring Location Settings (CLI) Y
Traffic classification Y
System event log Y
Ports & interfaces
Basic switching RJ-45 Ethernet ports quantity 24
Basic switching RJ-45 Ethernet ports type Gigabit Ethernet (10/100/1000)
SFP module slots quantity 4
Console port RJ-45/Micro-USB
Power connector AC-in jack
Security
DHCP features DHCP relay, DHCP server
Access Control List (ACL) Y
IGMP snooping Y
Authentication type RADIUS
MAC address filtering Y
Loop protection Y
BPDU filtering/protection Y
Password protection Y
Weight & dimensions
Width 440 mm
Depth 220 mm
Height 44 mm
Packaging data
Cables included AC
Quick start guide Y
Power
Power source AC
Power supply included Y
AC input voltage 100 - 240 V
AC input frequency 50/60 Hz
Power consumption (max) 301.1 W
Multicast features
Multicast support Y
Design
Rack mounting Y
Product colour Grey
LED indicators Y
Number of fans 2 ventilator(en)
Operational conditions
Heat dissipation 1027.4 BTU/h
Storage temperature (T-T) -40 - 70 °C
Storage relative humidity (H-H) 5 - 90 procent
Operating temperature (T-T) 0 - 50 °C
Operating relative humidity (H-H) 10 - 90 procent
Performance
Internal memory 256 MB
Flash memory 32 MB
Technical details
Sustainability certificates CE, Federal Communications Commission (FCC), RoHS
Sustainability compliance Y
Power over Ethernet (PoE)
Power over Ethernet (PoE) Y
Power over Ethernet plus (PoE+) ports quantity 24
Total Power over Ethernet (PoE) budget 250 W
