Multiple Application Scenarios

Wi-Fi Coverage
Works with Access Points

Surveillance
Works with IP Cameras

Conference Call
Works with IP Phones

Wired Connections
Works with Non-PoE Devices such as PCs and Printers

Specification

Product
Product id	996991
Brand	TP-Link
Partnr	SG2206MP
EAN/UPC code	1210002602402
Warranty (months)	3 year limited warranty for normal product and 5 year warranty for managed switch
Data transmission
MAC address table	8000 entries
Switching capacity	12 Gbit/s
Jumbo frames support	Y
Jumbo frames	9
Packet buffer memory	4.1 MB
Network
Port mirroring	Y
Routing entries	230
Active link detection	Y
Spanning tree protocol	Y
Rate limiting	Y
Link aggregation	Y
VLAN support	Y
Management features
Switch layer	L2
Ports & interfaces
Basic switching RJ-45 Ethernet ports quantity	5
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Gigabit Ethernet (copper) ports quantity	5
Installed SFP modules quantity	1
Security
DHCP features	DHCP relay, DHCP server
IGMP snooping	Y
Loop protection	Y
Weight & dimensions
Width	158 mm
Depth	100.7 mm
Height	25.4 mm
Power
Power source	DC
Power supply included	Y
Number of power supply units	1
DC input voltage	53.5 V
Input current	1.31 A
Power consumption (max)	73.7 W
Design
Rack mounting	Y
Stackable	Y
Power over Ethernet (PoE)
Power over Ethernet (PoE)	Y
Power over Ethernet plus (PoE+) ports quantity	4
Power over Ethernet (PoE) power per port	30 W
Total Power over Ethernet (PoE) budget	63 W
