What This Product Does
Omada SG6654XHP, an advanced L3 managed PoE+ switch, is crafted for convergence layer requirements with features like L3 routing, rapid 10 Gbps wired connectivity, stacking, and redundant power supplies. It offers an impressive 1440 W PoE budget,* 48× gigabit RJ45 PoE+ ports, 6× 10 Gbps SFP+ slots, and physical stacking. Combined with centralized management, strong security, and comprehensive management features, SG6654XHP is an ideal, reliable network solution for SMBs, enterprises, and ISPs.

IEEE 802.3at/af-compliant Power over Ethernet
48× IEEE 802.3at/af-compliant PoE ports supply up to 1440 W total power to 802.3at and 802.3af devices,* with each port supplying up to 30 W power. Set up wireless access points, surveillance cameras, IP phones, and other PoE devices quickly and easily, without the hassle and cost of installing power cabling. Perpetual PoE ensures an uninterrupted power supply to connected devices even during switch reboots. Additionally, the switch retains PoE power settings across reboots, thanks to fast PoE functionality.

High-speed Connectivity and Powerful Stacking
48 gigabit RJ45 ports and 6× 10 Gbps SFP+ slots provide up to 216 Gbps switching capacity per unit. Up to 4 units of physical stacking with up to 864 Gbps switching capacity empower the networking structure with built-in redundancy and performance.

Abundant Layer 3 Capabilities
Comes with abundant Layer 3 routing protocols that support a scalable network. Static Routing, RIP, OSPF, ECMP, VRRP, DHCP Server, and DHCP Relay are supported. PIM-DM multicast routing protocol guarantees efficient routing for multicast groups.

Highly Available
Optional field-replaceable and hot-swappable redundant power supplies and VRRP make it an ideal choice for reliable networking architecture. ** ERPS supports rapid protection and recovery in a ring topology.

Enhanced Security Functions
Defend against a range of network threats with ACL support (IPv4 & IPv6), Dynamic ARP Inspection, IEEE 802.1X, MAB, Port Security, and Secure Shell.

Omada SDN
Integration into the Omada system brings centralized cloud management and a series of management features such as Zero-Touch Provisioning (ZTP). ‡ The Omada Software Defined Networking (SDN) platform integrates network devices, including access points, switches, and routers, providing 100% centralized cloud management—all controlled from a single interface.

Apart from the ability to be centrally managed via the web or the Omada app, SG6654XHP is also easy to manage via an intuitive web-based Graphical User Interface (GUI) or an industry-standard Command Line Interface (CLI). For both management methods, traffic is protected through SSL or SSH encryption. SNMP (v1/v2c/v3) and RMON support enable the switch to be polled for valuable status information and to send traps for abnormal events.


Product id 948411
Brand TP-Link
Partnr SG6654XHP
EAN/UPC code 4895252501414
Warranty (months) 3 year limited warranty for normal product and 5 year warranty for managed switch
Data transmission
MAC address table 32000 entries
Switching capacity 216 Gbit/s
Forwarding rate 160.7 Mpps
Static route Y
Jumbo frames support Y
Jumbo frames 9000
Packet buffer memory 3 MB
Networking standards IEEE 802.1Q, IEEE 802.1p, IEEE 802.3x
10G support N
Port mirroring Y
IP routing Y
Flow control support Y
Spanning tree protocol Y
Rate limiting Y
Broadcast storm control Y
Ethernet LAN data rates 10, 100, 1000 Mbit/s
VLAN support Y
Virtual LAN features MAC address-based VLAN, Multicast VLAN, Private VLAN, Voice VLAN
Number of VLANs 4000
Management features
Switch type Managed
Switch layer L3
Quality of Service (QoS) support Y
Cloud-managed Y
Web-based management Y
Configuring Location Settings (CLI) Y
ARP inspection Y
System event log Y
Ports & interfaces
Basic switching RJ-45 Ethernet ports quantity 48
Basic switching RJ-45 Ethernet ports type Gigabit Ethernet (10/100/1000)
SFP+ module slots quantity 6
Console port RJ-45/USB Type-C
USB 2.0 ports quantity 2
DHCP features DHCP relay, DHCP snooping, DHCPv6 snooping
Access Control List (ACL) Y
IGMP entries 2048
IGMP snooping Y
Authentication type RADIUS
SSH/SSL support Y
Loop protection Y
Authentication Auto VLAN, MAC-based authentication, Port-based authentication
Weight & dimensions
Width 440 mm
Depth 420 mm
Height 44 mm
Packaging data
Cables included AC, LAN (RJ-45)
Manual Y
Power source AC
Power supply included Y
AC input voltage 100 - 240 V
AC input frequency 50/60 Hz
Power consumption (max) 1767.7 W
Multicast features
Multicast support Y
Rack mounting Y
Stackable Y
Form factor 1U
Product colour Black
LED indicators Y
Number of fans 4 ventilator(en)
Operational conditions
Heat dissipation 6027.86 BTU/h
Storage temperature (T-T) -40 - 70 °C
Storage relative humidity (H-H) 5 - 90 procent
Operating temperature (T-T) -5 - 40 °C
Operating relative humidity (H-H) 10 - 90 procent
Power over Ethernet (PoE)
Power over Ethernet (PoE) Y
Power over Ethernet plus (PoE+) ports quantity 48
Power over Ethernet (PoE) power per port 30 W
Total Power over Ethernet (PoE) budget 1440 W
