Smart. Secure. Easy.
Always Know Who’s There

2K 5MP Head-to-Toe 180° DFOV
Details matter, and with 2K 5MP clarity, D235 exceeds traditional Full HD resolution with finer details and incredible clarity. Experience the full picture with our 180° ultra-wide field of view, capturing every detail from head to toe in a single sweeping glance.

Flexible Wedges, Flexible Views
Different wedge choices give users possibilities to make the doorbell suits more placement scenarios. Users can also use these wedges to adjust the views.

Local and Cloud Storage
Save recorded videos on the microSD Card* (up to 512 GB, purchased separately) or use Tapo Care cloud storage services (subscribe separately).

Smart AI Detection and Notification
Smart AI identifies people, pets, vehicles, and packages, notifying users as needed.

Specification

Product
Product id	959029
Brand	TP-Link
Partnr	TAPO D235
EAN/UPC code	4895252501254
Features
International Protection (IP) code	IP66
Built-in spotlight	Y
Motion detection supported	Y
Detection angle	130 °
Human detection	Y
Product colour	Black, White
Package detection	Y
Mounting type	Wall
Night-light	Y
Certification	CE, RoHS, RCM, R-NZ, FCC, EAC, Triman, UKCA
LED type	IR
Easy to install	Y
Performance
Reset button	Y
Camera
Built-in camera	Y
Megapixel	5 MP
Maximum video resolution	2560 x 1920 Pixels
Maximum frame rate	15 fps
Sensor type	CMOS
Image sensor size	1/2.7 "
Fixed focal length	1.18 mm
Maximum aperture number	1.18
Night vision	Y
Night vision distance	10 m
Diagonal field of view	170.6 °
Ports & interfaces
Connectivity technology	Wireless
Wi-Fi	Y
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Security algorithms	WPA, WPA2-PSK
Frequency	2400 MHz
Mobile operating systems supported	Android 10, Android 10.0, Android 11.0, Android 12.0, Android 13.0, Android 4.4, Android 5.0, Android 5.1, Android 6.0, Android 7.0, Android 7.1, Android 7.1.2, Android 8.0, Android 8.1, Android 9.0, iOS 10.0, iOS 11.0, iOS 11.4, iOS 12, iOS 13, iOS 13.4, iOS 14, iOS 14.5, iOS 15, iOS 16, iOS 9.0, iOS 9.1, iOS 9.2, iOS 9.3
Networking standards	IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Supported network protocols	TCP/IP, DHCP, ICMP, DNS, NTP, HTTPS, TCP, UDP
Power
Power source type	Battery, DC
Input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Battery capacity	10000 mAh
Battery type	Lithium-Ion (Li-Ion)
Rechargeable battery	Y
Weight & dimensions
Width	73 mm
Bell width	150 mm
Depth	48 mm
Bell depth	38.4 mm
Height	54.6 mm
Bell height	50 mm
Operational conditions
Operating temperature (T-T)	-20 - 45 °C
Storage temperature (T-T)	-40 - 60 °C
Operating relative humidity (H-H)	10 - 90 procent
Storage relative humidity (H-H)	5 - 95 procent
