TP-Link VIGI NVR4016H. Video input channels: 16 channels, Maximum resolution: 3840 x 2160 pixels, Number of simultaneously playbacked channels: 16 channels. Maximum storage capacity: 16 TB, HDD interface: SATA. Ethernet LAN data rates: 10, 100, 1000 Mbit/s, Supported network protocols: UPnP (Plug and Play), NTP (Network Timing), SMTP, DNS, TCP/IP, UDP, ICMP, HTTP, HTTPS, DHCP, RTSP,. . . . Product colour: Black. Power consumption (max): 45 W, AC input voltage: 100 - 240 V, AC input frequency: 50/60 Hz

Specification

Product
Product id	985514
Brand	TP-Link
Partnr	VIGI NVR4016H
EAN/UPC code	8885020623666
Performance
Video input channels	16 kanalen
Alarm input channels	16
Number of simultaneously playbacked channels	16 kanalen
Alarm output channels	4
Video recording modes	720p, 1080p
Supported resolutions	3840x2160/30Hz, 1920x1080/60Hz, 1680x1050/60Hz, 1440x900/60Hz, 1280x1024/60Hz, 1280x720/60Hz
Maximum resolution	3840 x 2160 Pixels
Video motion detection	Y
Video loss detection	Y
Video formats supported	H.264, H.264+, H.265, H.265+
Backup function	Y
Input bandwidth	320 Mbit/s
Playback modes	Digital zoom, Fast play, Forward, Full screen, Pause, Play, Stop
Output bandwidth	320 Mbit/s
Recording modes	Manual, Schedule
Audio system	2-way
Storage
Number of HDDs supported	4
Maximum storage capacity	16 TB
HDD interface	SATA
Ports & interfaces
Ethernet LAN (RJ-45) ports	2
Ethernet LAN data rates	10, 100, 1000 Mbit/s
HDMI ports quantity	2
VGA (D-Sub) output ports	1
USB 2.0 ports quantity	2
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	1
eSATA ports quantity	1
Audio output	1
Line-in	Y
RS-232 ports	1
Supported network protocols	UPnP (Plug and Play), NTP (Network Timing), SMTP, DNS, TCP/IP, UDP, ICMP, HTTP, HTTPS, DHCP, RTSP, SSL/TLS, RTP, IPv4, ARP
Features
Rack mounting	Y
Reset button	Y
Buzzer off	Y
Product colour	Black
Power
Power consumption (max)	45 W
AC input voltage	100 - 240 V
AC input frequency	50/60 Hz
Output current	1.5 A
System requirements
Mobile operating systems supported	Android, iOS
Browser supported	Chrome (57+), Firefox (52+), Edge (91+)
Operational conditions
Operating temperature (T-T)	-10 - 55 °C
Operating relative humidity (H-H)	10 - 90 procent
Weight & dimensions
Width	440 mm
Depth	330 mm
Height	44 mm
Weight	4000 g
Package width	440 mm
Package depth	528 mm
Package height	100 mm
Package weight	5000 g
Packaging content
Cables included	AC, Power
Quick installation guide	Y
