Affordability and simplicity delivered
2D barcodes have made their way to your Point of Sale, appearing on everything from the items your customers are purchasing to printed and electronic coupons and loyalty cards.

Your 1D scanner can’t capture the new 2D codes, leading to exceptions that slow down the cheque-out process and frustrate customers at that key last personal touchpoint in your store.

But with the DS2200 Series, you can scan it all. You get an affordable 1D/2D imager that doesn’t compromise performance or features for price. And you can choose the model that best fits your POS needs — the corded DS2208 or the cordless DS2278. The DS2200 Series — the affordability your budget demands, with the deployment, ease of use and management simplicity your business requires.

Specification

Product
Product id	583647
Brand	Zebra
Partnr	DS2278-SR7U2100PRW
EAN/UPC code	4060533180224
Warranty (months)	36 months
Scanning
Type	Handheld bar code reader
Scanner type	1D/2D
Sensor type	LED
2D (matrix & stacked) barcodes supported	Aztec Code, Composite Codes, Data Matrix, Han Xin, MaxiCode, Micro QR Code, PDF417, QR Code, TLC-39
Linear (1D) barcodes supported	Codabar, Code 11, Code 128, Code 39, Code 93, EAN-13, Interleaved 2 of 5, Plessey, U. P. C.
Optical sensor resolution (W x H)	640 x 480 Pixels
Working distance	368 mm
Wavelength	645 nm
Tilt reading angle	-65 - 65 °
Pitch reading angle	-65 - 65 °
Motion tolerance (cm/s)	13
Ports & interfaces
Connectivity technology	Wired & Wireless
Standard interfaces	Bluetooth, USB
Bluetooth version	4.0
Bluetooth Low Energy (BLE)	Y
Performance
Product colour	Black
International Protection (IP) code	IP42
LED indicators	Y
Built-in display	N
Certification	EN 60950-1 2ed + A11 + A1 + A12 + A2:2013, IEC 60950-1 2ed + A1 + A2, UL 60950-1, CAN/CSA-C22.2 No. 60950- 1-07
Power
Power source type	Battery, DC
Battery technology	Lithium-Ion (Li-Ion)
Number of batteries supported	1
Battery capacity	2400 mAh
Battery life	84 uur
Input voltage	4.5 - 5.5 V
Weight & dimensions
Width	66 mm
Depth	90 mm
Height	175 mm
Weight	214 g
Technical details
Harmonized System (HS) code	84716070
Compliance certificates	RoHS
Packaging data
Charging base	Y
Operational conditions
Operating temperature (T-T)	0 - 50 °C
Storage temperature (T-T)	-40 - 70 °C
Operating relative humidity (H-H)	5 - 95 procent
