Your Secured Connection to the World

Secure your cross-group network
The ZyWALL VPN1000 is equipped with comprehensive VPN connection types including SSL & IPsec VPN, offering businesses secured remote connections.

IPsec VPN hardware engine for high efficiency VPN tunnel and VPN load balance/failover with SHA-2 algorithm and IKEv2 that ensures strong VPN reliability and security for business.

Reliance on cloud platforms for mission-critical services are growing, VPN1000 is validated by Microsoft Azure and AWS for SMB convenience by using a combination of on-site and cloud-based infrastructure with hybrid networks.

Why should your business adopt SD-WAN

Greater Agility
Quick installation. Remote control. Centralized monitoring

Higher Throughput
Advanced WAN technology boosts throughput performance

Lower Cost
Improve network quality without extra bandwidth investment

Content Filtering
Strengthen security by blocking access to malicious or risky websites. Prevents malware downloads from compromised or hacked websites.

Geo Enforcer
Monitors traffic and analyzes log data of IP address locations while denying access from unnecessary or potentially dangerous traffic.

Comprehensive connectivity
The ZyWALL VPN1000 combines AP Controller technology enabling users to manage up to 1032 APs from a centralized user interface. Businesses can deploy or expand a managed WiFi network with minimal effort.

Non-stop service
VPN features multi-WAN load balancing and failover safety with USB 3G/4G support as a backup WAN. ZyWALL VPN100 and higher provides active/passive device High-Availability (HA) service for non-stop internet connection service even when one device is broken.

Specification

Product
Product id	671629
Brand	ZyXEL
Partnr	VPN1000-EU0101F
EAN/UPC code	4718937610105
Technical details
Rack mounting	Y
Heat dissipation	120.1 BTU/h
Data transmission
Maximum data transfer rate	1000 Mbit/s
Firewall throughput	8000 Mbit/s
VPN throughput	1500 Mbit/s
Performance
Mean time between failures (MTBF)	444930 uur
Network
Concurrent SSL/VPN connections (maximum)	500
Concurrent SSL/VPN connections (default)	250
VPN tunnels quantity	1000
Dynamic DNS (DDNS)	Y
Number of VLANs	128
Point-to-point protocol over Ethernet (PPPoE)	Y
DHCP server	Y
DHCP client	Y
Security
Security algorithms	3DES, 256-bit AES, DES
Protocols
Management protocols	SNMP v1, v2c, v3
Ports & interfaces
Connectivity technology	Wired
Gigabit Ethernet (copper) ports quantity	12
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	2
Number of console ports	1
SFP module slots quantity	2
Certificates
Certification	FCC Part 15 (Class A), CE EMC (Class A), C-Tick (Class A), BSMI
Power
AC input voltage	100-240 V
AC input frequency	50/60 Hz
Input current	2.5 A
Power consumption (max)	46 W
Operational conditions
Operating temperature (T-T)	0 - 40 °C
Storage temperature (T-T)	-30 - 70 °C
Operating relative humidity (H-H)	10 - 90 procent
Storage relative humidity (H-H)	10 - 90 procent
Weight & dimensions
Width	400 mm
Depth	250 mm
Height	44 mm
Weight	3300 g
Packaging data
Package width	519 mm
Package height	392 mm
Package depth	163 mm
Package weight	4800 g
Packaging content
Cables included	AC
Rack mount kit	Y
