Extend and distribute a VGA signal to up to 8 displays over Cat5 cable

The ST1218T 8 Port VGA Video Extender over Cat 5 is designed for use with our ST121 VGA over Cat 5 extension series, offering convenient VGA video distribution at distances of up to 492 feet (150 meters) using standard Cat 5 (or better) cabling. Comprised of the transmitter unit only, the ST1218T requires one ST121R" text="Receiver Unit (ST121R) per display that you are connecting. For added versatility, the ST121EXT" text=" VGA over Cat 5 Repeater (ST121EXT) can be used to extend the distance between the transmitter and receiver by an additional 492-feet (150 meters), for a total distance of 984-feet (300 meters). Similarly, up to 3 repeater units can be used between transmitter and receiver, enabling you to connect monitors at each repeater, while still extending the total distance. Backed by a StarTech. com 2-year warranty and free lifetime technical support.

The StarTech. com Advantage

- Cat 5 extension enables you to make use of existing Ethernet infrastructure wiring to extend VGA video
- A pure hardware design provides an easy installation and setup, with no software or drivers required
- Support for cascading multiple transmitter units, and the use of repeaters for additional distance, providing a scalable system for VGA distribution

Specification

Product
Product id	349819
Brand	StarTech.com
Partnr	ST1218T
EAN/UPC code	065030830584
Warranty (months)	2 Year Warranty
Features
Type	AV receiver
Maximum resolution	1600 x 1200 Pixels
Cable types supported	Cat5
Maximum transfer distance	150 m
LED indicators	Activity, Power
Supported graphics resolutions	1024 x 768 (XGA), 1280 x 1024 (SXGA), 1600 x 1200 (UXGA)
Product colour	Black
Ports & interfaces
Ethernet LAN	Y
VGA (D-Sub) output ports	2
VGA (D-Sub) input ports	1
DC-in jack	Y
Power
AC input voltage	115 V
Packaging data
Package width	94 mm
Package depth	239 mm
Package height	187 mm
Package weight	760 g
Packaging content
AC adapter included	Y
Manual	Y
Technical details
Compliance certificates	RoHS
