The Neomounts by Newstar FPMA-C020BLACK is a tilt- and swivel ceiling mount for flat screens up to 40" (102 cm). This mount is a great choice for space saving placement or when wall mounting and floor placement is not an option.

Neomounts by Newstar's versatile tilt (90°) technology allows the mount to change to any viewing angle to fully benefit from the capabilities of the flat screen. The support is easily height adjustable from 26, 5 to 40 centimetres. An innovative cable management conceals and routes cables from ceiling to TV. Hide your cables in the column to keep it nice and tidy.

Neomounts by Newstar FPMA-C020BLACK has one pivot point and is suitable for screens up to 40" (102 cm). The weight capacity of this product is 20 kg. The ceiling mount is suitable for screens that meet VESA hole pattern 75x75 or 200x200mm. Different hole patterns can be covered using Neomounts by Newstar VESA adapter plates.

All installation material is included with the product.

Specification

Product
Product id	561307
Brand	Neomounts
Partnr	FPMA-C020BLACK
EAN/UPC code	8717371445690
Warranty (months)	5 year
Mounting
Maximum weight capacity	20 kg
Mounting type	Ceiling
Minimum screen size compatibility	10 "
Maximum screen size	40
Minimum VESA mount	75 x 75 mm
Maximum VESA mount	200 x 200 mm
Panel mounting interface	75 x 75, 75 x 200, 100 x 100, 100 x 200, 200 x 100, 200 x 200 mm
Ergonomics
Height adjustment type	Manual
Tilt adjustment	Y
Rotating	Y
Swivelling	Y
Height adjustment	Y
Height adjustment range	265 - 400 mm
Swivel angle	90 °
Tilt angle range	0 - 90 °
Type	Full motion
Technical details
Product colour	Black
Number of displays supported	1
Package net weight	1720 g
Design
Housing material	Steel
Weight & dimensions
Height	400 mm
Weight	1720 g
Packaging data
Package width	228 mm
Package depth	90 mm
Package height	330 mm
Package weight	1700 g
Other features
Country of origin	China
Logistics data
Master (outer) case width	745 mm
Master (outer) case length	245 mm
Master (outer) case height	345 mm
Master (outer) case weight	16800 g
Master (outer) case net weight	13760 g
Quantity per master (outer) case	8 stuk(s)
Harmonized System (HS) code	HS83025000
Quantity per EUR-pallet	120 stuk(s)
